TOKIMEC SQP1-8 Single Fixed Displacement Vane Pump, 8 cm³/rev, Low Noise, Counter-Clockwise Rotation, Design 15

TOKYO KEIKI SQP1-8 Single Fixed Displacement Vane Pump, 8 cm³/rev, Low Noise, Parallel Square Key, Counter-Clockwise Rotation, Design 15

The TOKYO KEIKI SQP1-8 is a high-performance, low-noise single fixed displacement vane pump, meticulously engineered for demanding industrial hydraulic applications. As a distinguished model within the renowned SQP series, it is acclaimed for its robust construction, exceptional efficiency, and significantly reduced operating noise levels, ensuring a more comfortable and productive working environment.

This specific configuration, SQP1-8, designates a single pump design, offering a precise displacement of 8 cm³/rev. This ensures a consistent and controlled flow rate crucial for various hydraulic functions. The shaft end is typically configured with a parallel square key (a standard connection for the SQP series), ensuring a secure and reliable mechanical connection to the drive system.

The rotational direction, denoted by "LH," indicates left-hand (counter-clockwise) rotation when viewed from the shaft end, which is essential for proper system integration. The model number also contains "1C" related to port positioning; however, detailed specifications for this specific coding format for the SQP1 series are not explicitly provided within the referenced documentation. While a delivery port exists, its precise orientation based on "1C" is not definitively interpretable from the available information. This pump is manufactured under Design Number 15, representing its specific revision and configuration.

Designed primarily for mineral oil-based hydraulic fluids, the SQP1-8 model ensures reliable operation across a broad spectrum of pressures and speeds. Its advanced vane pump technology guarantees stable flow and pressure, contributing to precise control and extended service life for your hydraulic systems. The incorporation of cutting-edge low-noise technology makes this pump particularly well-suited for applications where acoustic emissions are a critical concern, helping meet both environmental and workplace safety standards.

Manufacturer Information:

• Manufacturer: TOKYO KEIKI INC.
• Series: SQP Series, Low Noise Single Fixed Displacement Vane Pumps
• Model: SQP1
• Design Number: 15

Key Features:

• Single Fixed Displacement: Provides a precise and consistent flow rate of 8 cm³/rev for reliable hydraulic performance.
• Low Noise Operation: Engineered to minimize operational noise, enhancing workplace conditions and aiding compliance with acoustic regulations.
• High Efficiency: Delivers excellent volumetric and overall efficiency, contributing to reduced energy consumption and lower operating costs.
• Robust Construction: Manufactured with durable materials to ensure long-term reliability and resistance to wear in harsh industrial environments.
• Shaft End Configuration: Typically features a parallel square key for secure mechanical coupling.
• Counter-Clockwise Rotation (LH): Configured for left-hand (counter-clockwise) rotation when viewed from the shaft end, ensuring compatibility with specific drive systems.
• Wide Application Range: Ideal for various industrial machinery demanding reliable and controlled hydraulic power, including machine tools, presses, and material handling equipment.

By integrating the TOKYO KEIKI SQP1-8 pump, users can expect enhanced system performance, reduced maintenance requirements, and a significantly quieter operational footprint, making it a valuable and high-performing addition to modern hydraulic systems.
