SKF CR18652 iron shell oil seal (4 Pieces）

SKF CR18652 iron shell oil seal (4 Pieces）

$85.00 USD
$85.00 USD
Sale Sold out
Shipping calculated at checkout.

Secure checkout via Stripe & PayPal

Product Overview

A high-performance radial shaft seal designed for demanding rotary applications. Features a fluoro rubber (FKM) sealing lip and a metal-cased outer diameter with sealant coating. Suitable for –25 °C to 200 °C at speeds up to 9 900 rpm.

Key Features

  • Design: CRW1
  • Sealing lip: Fluoro rubber (FKM)
  • Auxiliary lip: None
  • Outer diameter: Metal-cased with sealant coating

Specifications

Parameter Value
Shaft diameter 1.875 in
Housing bore diameter 2.750 in
Seal width 0.313 in
Maximum rotational speed 9 900 rpm
Permissible circumferential speed 24.65 m/s
Operating temperature range –25 °C to 200 °C
Unit system Inch

Logistics & Classification

  • Net weight: 0.0226 kg
  • eCl@ss: 23-07-08-01
  • UNSPSC: 31181602
