SKF CR13945 iron shell oil seal (4 Pieces）
SKF CR13945 iron shell oil seal (4 Pieces）
Regular price
$45.00 USD
Regular price
Sale price
$45.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Stripe & PayPal
Product Overview
A solid-design radial shaft seal featuring dual straight lips in nitrile rubber (NBR) for reliable sealing in oil or grease applications. The rubber-covered steel casing with garter spring ensures consistent contact pressure and long service life.
Key Features
- Design type: HMSA7 (solid)
- Seal type: Rotary/radial shaft seal
- Lip material: Nitrile rubber (NBR)
- Lip configuration: 2 straight lips with carbon-steel garter spring
- Casing: Rubber-covered steel, rubber outside diameter
- Installation: Housing press fit
Specifications
| Parameter | Value |
|---|---|
| Shaft diameter | 1.378 in (35.00 mm) |
| Outside diameter | 1.850 in (47.00 mm) |
| Overall width | 0.276 in (7.01 mm) |
| Operating temperature range | –40 °F to 210 °F (–40 °C to 99 °C) |
| Pressure tolerance | 7 psi (0.48 bar) |
| Lubricants | Oil or grease |
| Weight | 0.03 lb (13.6 g) |
Compatibility
- Wear sleeves: 99139, 99820
- V-rings: 400350, 400351, 400354, 400355
Additional Information
- UPC: 085311992534
- Construction: Oil seal
