SKF 45X62X10HMSA10 RG iron shell oil seal (4 Pieces）

Name: SKF 45X62X10HMSA10 RG iron shell oil seal (4 Pieces）
Brand: SKF
Price: 80.00 USD
Availability: InStock

$80.00 USD

Sale Sold out

Shipping calculated at checkout.

Secure checkout via Stripe & PayPal

SKF 45X62X10 HMSA10 RG — Radial shaft seal (45 × 62 × 10 mm)

Overview

SKF HMSA10 radial shaft seal with rubber outside diameter and single sealing lip. Designed for oil or grease lubrication, the seal features a nitrile rubber (NBR) lip, garter spring, and a non‑contacting auxiliary (dust) lip to improve contamination exclusion and accommodate misalignment.

Key features

Design: HMSA10 (single sealing lip + non‑contacting auxiliary lip)
Lip material: Nitrile rubber (NBR)
Outside diameter: Rubber, metal‑reinforced
Spring: Garter spring for consistent lip contact pressure
Lubrication: Oil or grease
Standards: ISO 6194; DIN 3760

Specifications

Parameter	Metric	Imperial
Designation	45 × 62 × 10 mm	1.7717 × 2.4409 × 0.3937 in
Shaft diameter (d₁)	45.00 mm	1.7717 in
Housing bore diameter (D)	62.00 mm	2.4409 in
Seal width (b)	10.00 mm	0.3937 in
Limiting / max rotational speed	3 120 r/min	3 120 r/min
Permissible circumferential speed	7.40 m/s	1 456.693 ft/min
Operating temperature (min)	−40 °C	−40 °F
Operating temperature (max)	100 °C (short periods 120 °C)	212 °F (short periods 248 °F)
Pressure differential	0.05 N/mm²	7.252 psi
