Sinofuse RS309-MD High-Speed Fuse, 60A 500V AC/DC, aR Semiconductor Protection, Bolted Tag - Pack of 10

The Sinofuse RS309-MD is a professional-grade high-speed fuse specifically designed for the protection of power semiconductor devices. Engineered by Xi'an Sinofuse Electric Co., Ltd., this fuse-link features an "aR" utilization category, providing ultra-fast response to overcurrent events. It is a critical component for safeguarding diodes, thyristors, IGBTs, and other sensitive power electronic equipment in both AC and DC circuits.

Key Features

• Dual AC/DC Rating: Versatile application range with a 500V rating for both alternating and direct current systems.
• High Breaking Capacity: Engineered to safely interrupt fault currents up to 200kA in AC circuits and 50kA in DC circuits, preventing catastrophic equipment failure.
• Semiconductor Protection (aR): Ultra-fast acting characteristic ensures minimum energy let-through (I²t), providing superior protection for delicate power electronics.
• Global Standard Compliance: Fully certified under CE, UL (cURus), and RoHS standards, and manufactured according to IEC 60269 requirements for international reliability.
• Robust Bolted Construction: Features a blade-style mounting for secure bolted installation, ensuring stable electrical contact in high-vibration industrial environments.

Technical Specifications

• Manufacturer: Xi'an Sinofuse Electric Co., Ltd.
• Model Number: RS309-MD
• Product Code: 9800301628
• Rated Current: 60 A
• Rated Voltage: 500V AC / 500V DC
• Utilization Category: aR (Semiconductor Protection)
• Interrupting Rating: AC 200kA / DC 50kA
• Standard: IEC 60269
• Mounting Type: Bolted Tag / Center Blade
• Certifications: UL, CE, RoHS
• Package Quantity: 10 Pieces
