Sinofuse EV322-4GL80A 700VDC Series Fuse, 700VDC, 80A
Regular price
$12.00 USD
Regular price
Sale price
$12.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview
The Sinofuse EV322-4GL80A is a 700VDC series fuse designed for road vehicles, providing robust protection with its energy-efficient and compact design. This fuse features a high breaking capacity and meets standards such as JASO D622, ISO 8820, and GB/T 31465, making it perfect for electric vehicle drive power systems and energy storage applications.
Key Features
- Rated Voltage: 700VDC
- Rated Current: 80A
- Breaking Capacity: 50KA, L/R < 10ms
- Compliance: CE, RoHS
- Resistant to temperature shock, mechanical vibration, and chemical load
- Ideal for EV systems and energy storage solutions
Specifications
| Product ID | EV322-4GL80A |
| Series | 700VDC Road Vehicle Fuse |
| Rated Voltage | 700VDC |
| Rated Current | 80A |
| Breaking Capacity | 50KA, L/R < 10ms |
| Compliance | CE, RoHS |
