SINOFUSE EV322-4GL 25A 700VDC Bolt-On Fuse, 441 A²s, 4.6W
Regular price
$9.00 USD
Regular price
Sale price
$9.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview
The SINOFUSE EV322-4GL is a 700VDC bolt-on fuse specifically designed for road vehicles. It offers high breaking capacity and is suitable for use in electric vehicle power systems, energy storage, and other automotive applications. It adheres to standards such as JASOD622, ISO8820, and GB/T31465, and is compliant with CE and RoHS.
Key Features
- Voltage Rating: 700VDC
- Current Rating: 25A
- Breaking Capacity: 50KA, L/R<10ms
- Compact size with high breaking capability
- Resistant to temperature shock, mechanical vibration, and electrical/chemical stresses
Specifications
| Model | EV322-4GL25A |
| Rated Voltage (VDC) | 700 |
| Rated Current (A) | 25 |
| Breaking Capacity (kA) | 50 |
| I²t (A²s) | 75 |
| Power Loss (W) | 4.6 |
| Installation Torque (N·m) | 5.5 |
