• SINOFUSE SINOFUSE EV322-4GL 16A 700VDC Fuses (10 Pieces)
1 1

SINOFUSE EV322-4GL 16A 700VDC Bolt-On Fuse, 155 A²s, 3.2W

$10.00 USD
$10.00 USD
Sale Sold out
Shipping calculated at checkout.
Pack Size

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

Visa Mastercard PayPal Apple Pay Google Pay American Express
TECHNICAL DATASHEET PDF

Overview

The SINOFUSE EV322-4GL is a 700VDC bolt-on fuse specifically designed for road vehicles. It offers high breaking capacity and is suitable for use in electric vehicle power systems, energy storage, and other automotive applications. It adheres to standards such as JASOD622, ISO8820, and GB/T31465, and is compliant with CE and RoHS.

Key Features

  • Voltage Rating: 700VDC
  • Current Rating: 16A
  • Breaking Capacity: 50KA, L/R<10ms
  • Compact size with high breaking capability
  • Resistant to temperature shock, mechanical vibration, and electrical/chemical stresses

Specifications

Model EV322-4GL16A
Rated Voltage (VDC) 700
Rated Current (A) 16
Breaking Capacity (kA) 50
I²t (A²s) 26
Power Loss (W) 3.2
Installation Torque (N·m) 5.5
View full details
