Sinofuse EV315-L-3EC15A Electric Vehicle Fuse, 15A 500V DC, High-Speed Bolt-on - Pack of 10

The Sinofuse EV315-L-3EC15A is a high-performance, high-speed DC fuse engineered for the protection of critical auxiliary circuits in Electric Vehicle (EV) and Hybrid Electric Vehicle (HEV) systems. Rated for 15A at 500V DC, this fuse is specifically designed to safeguard components such as On-Board Chargers (OBC), DC/DC converters, and Power Distribution Units (PDU).

This component is manufactured to strict automotive quality standards, including ISO 8820 and JASO D622, ensuring exceptional reliability under harsh vehicle operating conditions. It features high-speed interruption capabilities that limit let-through energy (I²t), thereby protecting sensitive semiconductor devices from thermal damage during short-circuit or overcurrent events. The 3EC bolt-on terminal design ensures a high-integrity mechanical and electrical connection that is resistant to the intense vibrations and thermal cycling typical in automotive applications.

Technical Specifications

• Manufacturer: Sinofuse (Xi'an Sinofuse Electric Co., Ltd.)
• Model Number: EV315-L-3EC15A
• Current Rating: 15A
• Voltage Rating: 500V DC
• Interrupting Rating (Breaking Capacity): 20kA @ 500V DC
• Mounting Type: Bolt-on (3EC Terminal Type)
• Pre-arcing I²t: 40 A²s
• Total Clearing I²t: 135 A²s (@ 500V DC)
• Power Dissipation (Loss): 3.0W
• Operating Temperature Range: -40°C to +125°C
• Standards Compliance: ISO 8820, JASO D622, GB/T 31465, RoHS
• Primary Application: On-Board Chargers (OBC), DC/DC Converters, PDU Aux Circuits
• Quantity: Pack of 10
