Sinofuse EV315-C-3E30A Electric Vehicle Fuse, 30A 500V DC, 10x38mm High-Speed Ferrule

The Sinofuse EV315-C-3E30A is a professional-grade high-speed cylindrical fuse engineered for the protection of Electric Vehicle (EV) and Hybrid Electric Vehicle (HEV) systems. Rated at 30A with a 500V DC voltage capacity, it is designed to safeguard power conversion systems, battery management units, and on-board charging equipment from short-circuit and overcurrent events.

Constructed as a 10x38mm ferrule type, this fuse is optimized for high-density automotive power distribution modules. It features exceptional resistance to mechanical vibration, thermal shock, and chemical loads, meeting the stringent requirements of the road vehicle industry. With its low I²t clearing values and a 20kA breaking capacity, it ensures rapid interruption to protect sensitive semiconductor power electronics.

Technical Specifications

• Manufacturer: Sinofuse (Xi'an Sinofuse Electric Co., Ltd.)
• Model Number: EV315-C-3E30A
• Current Rating: 30A
• Voltage Rating: 500V DC
• Interrupting Rating (Breaking Capacity): 20kA DC (@ Time Constant: 2±0.5ms)
• Fuse Type: High-Speed / Ferrule
• Dimensions: 10 x 38 mm
• Pre-arcing I²t: 333 A²s
• Total Clearing I²t: 1025 A²s (at 520V DC)
• Power Dissipation (Loss): 6W
• Color Identifier: Green
• Operating Temperature Range: -40°C to +125°C
• Standards Compliance: ISO8820, JASO D622, GB/T31465, RoHS
• Mounting Style: Ferrule (Clip-style mounting)
