SIEMENS 6ES7677-1DD10-0BA0 SIMATIC S7-modular embedded Controller

Siemens SIMATIC IOT2040 Industrial IoT Gateway

The Siemens SIMATIC IOT2040 is a reliable, open platform designed for acquiring, processing, and forwarding data directly within the production environment. It acts as an intelligent gateway, seamlessly bridging the gap between automation (Operational Technology - OT) and Information Technology (IT). This device is ideal for retrofitting existing plants and cost-effectively implementing Industrial Internet of Things (IIoT) solutions.

Built for industrial applications, the IOT2040 offers flexibility through its support for Yocto Linux and high-level programming languages, allowing for customized data handling and communication tasks.

Key Features:

• Open Platform: Based on an Intel Quark processor and Yocto Linux for maximum flexibility and customization.
• Programming Freedom: Enables development using high-level languages such as Java, C++, Python, and others.
• Versatile Connectivity: Equipped with multiple interfaces including Ethernet, USB, and serial ports (RS232/485).
• Expandability: Features an Arduino shield slot and an mPCIe slot for adding custom I/O, wireless connectivity, or other functionalities.
• Industrial Design: Robust construction suitable for deployment in industrial environments.
• Easy Integration: Designed for straightforward integration into existing automation networks and IT systems.
• Flexible Mounting: Supports both standard DIN rail mounting and wall mounting.

Technical Specifications:

• Brand: Siemens
• Model: SIMATIC IOT2040
• Order Number: 6ES7677-1DD10-0BA0
• Processor: Intel Quark x1020 (+LPE) (1 Core, 400 MHz)
• Memory (RAM): 1 GByte DDR3L
• Storage: SD/SDHC card slot (up to 32 GB) for Operating System and User Data
• Interfaces:
  • 2 x Ethernet RJ45 (10/100 Mbit/s, independent interfaces)
  • 1 x COM (RS232 / RS485, switchable)
  • 1 x COM (RS232)
  • 2 x USB 2.0 Host (Type A)
• Expansion Slots:
  • 1 x Arduino UNO R3 Shield Slot
  • 1 x mPCIe Slot (half-size / full-size, PCIe + USB)
• Supply Voltage: 24 V DC
• Permissible Voltage Range: 9 V DC to 36 V DC
• Mounting: 35mm DIN rail, Wall mount
• Operating Temperature (horizontal installation): 0 °C to +50 °C
• Product Width: 144 mm
• Product Height: 90 mm
• Product Depth: 55.6 mm
• Product Weight (Net): Approx. 0.44 kg
• Compliances / Certifications: CE mark, UL Listed (UL 61010-1, UL 61010-2-201), cULus, FM Approved (Class I Div 2), KC approval, RCM mark
