Siemens 6ES7138-4DB03-0AB0 SIMATIC DP Electronics Module, SSI 25 bit/1 MHz, 15mm Width
Regular price
$130.00 USD
Regular price
Sale price
$130.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
| Product Name | SIMATIC DP Electronics Module |
| Product ID | 6ES7138-4DB03-0AB0 |
| Supply Voltage | 24 V DC |
| Permissible Voltage Range | 20.4 V to 28.8 V DC |
| Reverse Polarity Protection | Yes |
| Input Current from Load Voltage L+ | 40 mA |
| Input Current from Backplane Bus | 10 mA |
| Encoder Supply Voltage | 24 V |
| Short-circuit Protection (Encoder) | Yes |
| Output Current (Encoder), max. | 500 mA |
| Power Loss, typ. | 1 W |
| Digital Inputs | 1 |
| Input Voltage for Signal "0" | -30 to +5 V |
| Input Voltage for Signal "1" | +11 to +30V |
| Connectable Encoders | 1; Absolute encoder (SSI), 2-wire sensor |
| Telegram Length, parameterizable | 13, 14, 16, 21, 24 & 25 bit |
| Dimensions (Width x Height x Depth) | 15 mm x 81 mm x 52 mm |
| Weight, approx. | 40 g |
