SIEMENS 6ES7138-4FA04-0AB0 Electronics Module, 24V DC, 8 Digital Inputs
Regular price
$180.00 USD
Regular price
Sale price
$180.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SIEMENS 6ES7138-4FA04-0AB0 is an advanced electronics module designed for high-performance applications requiring reliable and precise control. Engineered with a 24V DC rated supply voltage, this module features 8 digital inputs and 2 output channels with electronic short-circuit protection, making it ideal for various industrial environments.
| Supply Voltage Rated Value (DC) | 24 V |
| Reverse Polarity Protection | No |
| Number of Outputs | 2 |
| Type of Output Voltage | min. L+ (-1.5 V) |
| Short-circuit Protection | Yes; Electronic (response threshold 0.7 A to 1.8 A) |
| Rated Output Current | 300 mA |
| Power Loss (typ.) | 4 W |
| Address Space per Module Inputs | 6 byte |
| Address Space per Module Outputs | 4 byte |
| Number of Digital Inputs | 8; 8 single channel, 4 two-channel |
| Input Characteristic Curve IEC 61131 Type 1 | Yes |
| Type of Input Voltage | DC |
| Input Voltage Rated Value (DC) | 24 V |
| Input Voltage for Signal "0" | -30 to +5 V |
| Input Voltage for Signal "1" | +15 to +30 V |
| Input Current for Signal "1" (typ.) | 3.7 mA |
| Input Delay for "0" to "1" (min.) | 0.3 ms |
| Input Delay for "0" to "1" (max.) | 17 ms |
| Input Delay for "1" to "0" (min.) | 0.3 ms |
| Input Delay for "1" to "0" (max.) | 17 ms |
| Cable Length (shielded, max.) | 200 m |
| Cable Length (unshielded, max.) | 200 m |
| Connectable Encoders (2-wire sensor) | No |
| Diagnostics Function | Yes |
| Diagnostic Alarm | Yes |
| Diagnostic Information Readable | Yes |
| Short-circuit Diagnosis | Yes |
| Diagnostics Indication LED (Group error SF, red) | Yes |
| Diagnostics Indication LED (Status indicator digital input, green) | Yes |
| Potential Separation Digital Inputs (between the channels) | No |
| Potential Separation Digital Inputs (between the channels and backplane bus) | Yes |
| Potential Separation Digital Inputs (between the channels and load voltage L+) | No |
| Isolation Tested with | 500 V DC |
| Highest Safety Class Achievable in Safety Mode (EN 954) | 4 |
| Performance Level According to ISO 13849-1 | e |
| SIL Acc. to IEC 61508 | SIL 2 (single-channel), SIL 3 (two-channel) |
| Dimensions (W x H x D) | 30 mm x 81 mm x 52 mm |
| Weight | 78 g |
