Siemens 6ES7138-4CA01-0AA0 SIMATIC DP PM-E Power Module, 24 V DC, Diagnostics Enabled
Regular price
$40.00 USD
Regular price
Sale price
$40.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
| Product Name | SIMATIC DP PM-E Power Module |
| Product ID | 6ES7138-4CA01-0AA0 |
| Supply Voltage | 24 V DC |
| Short-circuit Protection | No; external (e.g. automatic circuit breaker), tripping characteristic C |
| Reverse Polarity Protection | Yes |
| Input Current from Load Voltage L+ (without load), max. | 4 mA |
| Current Carrying Capacity up to 60 °C, max. | 10 A |
| Power Loss, typ. | 0.1 W |
| Diagnoses Missing Load Voltage | Yes |
| Diagnostics Indication LED Rated Load Voltage PWR (green) | Yes |
| Diagnostics Indication LED Group Error SF (red) | Yes |
| Parameter Remark | 3 byte |
| Missing Load Voltage | Disable / enable |
| Potential Separation | Yes; between rated load voltage and backplane bus, between power modules |
| Isolation Tested with | 500 V DC |
| Dimensions (Width x Height x Depth) | 15 mm x 81 mm x 52 mm |
| Weight, approx. | 35 g |
