Siemens 6ES7134-4FB01-0AB0 ET 200S Electronics Module, 2 AI Standard U, 15mm Width
Regular price
$200.00 USD
Regular price
Sale price
$200.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview
The Siemens 6ES7134-4FB01-0AB0 is an electronics module for the ET 200S series, providing 2 analog inputs in a 15mm width package. It supports input ranges of +/-10V at 13-bit plus sign, +/-5V at 12-bit plus sign, and 1-5V at 12-bit resolution. The module includes features like group fault LED indication and is designed for various industrial applications.
Key Features
- 2 Analog Inputs
- Supports +/-10V, +/-5V, and 1-5V Ranges
- Resolution: Up to 14 bit
- Smoothing of Measured Values in Four Stages
- Diagnostic Features: Wire-Break, Group Error
Specifications
| Supply Voltage L+ | 24V DC |
| Reverse Polarity Protection | Yes |
| Input Current from Load Voltage L+ | 30 mA max. |
| Power Loss | 0.6 W typ. |
| Analog Inputs | 2 |
| Permissible Input Voltage (Destruction Limit) | 35V continuous; 75V for max. 1 ms |
| Cable Length Shielded | 200 m max. |
| Isolation | 500 V DC tested |
| Dimensions (W x H x D) | 15 mm x 81 mm x 52 mm |
| Weight | Approx. 40 g |
