Telemecanique Sensors XUX9ARCNT16 XUX Photoelectric Sensor, Polarised Reflex 11 m, 24–240 V AC/DC
Regular price
$195.00 USD
Regular price
Sale price
$195.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Telemecanique Sensors XUX9ARCNT16 is a compact polarised-reflex photoelectric sensor designed for general-purpose detection tasks. Offering a nominal sensing distance of 11 m (with reflector XUZC50) and a wide 24…240 V AC/DC power range, it provides a single change-over relay output and clear LED status indication. Rugged PBT housing, IP65/IP67 protection and global approvals ensure reliable operation in industrial environments.
Key Features
- Polarised reflex detection, 11 m nominal range (15 m max)
- Wide supply voltage: 24…240 V AC/DC (20…264 V limits)
- Relay output: 1 C/O, 3 A at 250 V AC (cos φ = 1)
- Compact housing: 92 × 31 × 77 mm (H × W × D)
- IP65 & IP67 with double insulation
- Sensitivity adjustment and three-colour status LEDs
- UL, CSA, CE certified; 18-month warranty
| Product ID | XUX9ARCNT16 |
| Brand | Telemecanique Sensors |
| Range | Telemecanique Photoelectric Sensors XU |
| Series / Device Short Name | XUX |
| Product Type | Photoelectric Sensor |
| GTIN / EAN | 3389110171532 |
| Detection System | Polarised reflex |
| Nominal Sensing Distance (Sn) | 11 m |
| Maximum Sensing Distance | 15 m |
| Required Reflector | XUZC50 |
| Output Type | Relay (1 C/O) |
| Switching Capacity | 3 A @ 250 V AC (cos φ = 1) |
| Supply Voltage (Us) | 24…240 V AC/DC |
| Supply Voltage Limits | 20…264 V AC |
| Current Consumption (no-load) | ≤ 35 mA |
| Power Consumption | 2 W |
| Switching Frequency | ≤ 20 Hz |
| Response Time | 25 ms |
| Recovery Time | 25 ms |
| Delay First Up | 60 ms |
| Status LEDs | Yellow (output), Red (instability), Green (supply) |
| Housing Material | PBT; Lens: PMMA |
| Cable Entry | M16 × 1.5 (Ø 7–10 mm) |
| Electrical Connection | Screw-clamp terminals (1 × 1.5 mm² or 1 × 0.75 mm²) |
| Wiring Technique | 5-wire |
| IP Rating | IP65 / IP67 |
| Operating Temperature | -25…+55 °C |
| Storage Temperature | -40…+70 °C |
| Vibration Resistance | 7 gn, 10–55 Hz (IEC 60068-2-6) |
| Shock Resistance | 30 gn, 11 ms (IEC 60068-2-27) |
| Dimensions (H × W × D) | 92 × 31 × 77 mm |
| Net Weight | 0.20 kg |
| Certifications | UL, CSA, CE |
| Country of Origin | Indonesia |
| Warranty | 18 months |
