Schneider TM2DDI16DK Discrete Input Module, 16-Channel 24VDC (Sink/Source), HE10 Connector, for Modicon M238 Logic Controllers

Schneider TM2DDI16DK Discrete Input Module

Product Overview: The Schneider TM2DDI16DK is a discrete input expansion module engineered to enhance the digital input capabilities of Modicon M238 logic controllers. This module provides 16 robust digital input channels, operating at 24V DC and supporting flexible sink or source logic. Equipped with a high-density HE10 connector, the TM2DDI16DK offers a compact, efficient, and reliable solution for integrating a wide array of digital sensors and control signals into industrial automation systems, effectively expanding the input capacity of Modicon M238 PLCs. It is also compatible with Twido and Advantys OTB ranges, and Magelis HMI controllers.

Key Features:

• 16 Digital Inputs: Supplies a substantial number of input channels for diverse application requirements.
• 24VDC Operation: Adheres to industrial standard voltage for compatibility with most common digital sensors.
• Sink/Source Logic: Offers flexible wiring configurations to interface with various sensor types and control schemes.
• HE10 Connector: Features a high-density HE10 connector for streamlined wiring and space efficiency.
• Fast Response Time: Delivers a rapid 4 ms response time for both ON and OFF states, ensuring prompt signal acquisition.
• Robust Isolation: Incorporates 500 V isolation between channels and internal logic for enhanced electrical safety and signal fidelity.
• Compact & DIN Rail Mountable: Designed for efficient use of panel space, easily mounting on a standard 35 mm symmetrical DIN rail.
• Broad Compatibility: Specifically designed for Modicon M238 logic controllers, with compatibility extending to Advantys OTB, Twido, and Magelis HMI controllers.

Technical Specifications:

• Manufacturer: Schneider Electric
• Part Number: TM2DDI16DK
• Product Series: Modicon TM2 Expansion Modules (for Modicon M238)
• Product Type: Discrete Input Module
• Number of Discrete Inputs: 16 channels
• Input Voltage: 24 VDC
• Input Voltage Limits: 20.4 to 28.8 V
• Discrete Input Logic: Sink or Source
• Discrete Input Current: 5 mA
• Input Impedance: 4.4 kOhm
• Number of Common Points: 1
• Response Time: 4 ms (from state 0 to state 1), 4 ms (from state 1 to state 0)
• Isolation: 500 V for 1 minute (between channels and internal logic)
• Current Consumption: 35 mA at 5 V DC (for all inputs at state 1)
• Local Signalling: 2 display blocks
• Electrical Connection: 1 x HE10 connector
• Mounting Support: 35 mm symmetrical DIN rail
• Dimensions (WxDxH): 21.4 mm x 81.3 mm x 90 mm (0.8 in x 3.2 in x 3.5 in)
• Net Weight: 0.1 kg (0.2 lb US)
