Schneider Electric LP2K1210BD TeSys K Reversing Contactor, 3P 12 A, 24 V DC Coil
Regular price
$100.00 USD
Regular price
Sale price
$100.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric TeSys K LP2K1210BD is a pre-assembled 3-pole reversing contactor with mechanical interlock and integrated power busbar. Rated for motor loads up to 12 A (AC-3) at 440 V, it features a standard 24 V DC control coil, one NO auxiliary contact, and screw-clamp terminals. High making capacity, extended electrical life, and compact dimensions make it ideal for bidirectional motor control in industrial panels.
Key Features
- Reversing contactor with mechanical interlock and busbar
- 3 NO power poles + 1 NO auxiliary contact
- Rated operational current: 12 A (AC-3) at ≤ 440 V AC
- 24 V DC standard coil, 3 W inrush/hold
- High making capacity: 144 A (IEC 60947)
- Mechanical life: 5 million cycles
- Compact size: 58 × 90 × 57 mm (H × W × D)
- IP20 protection, IEC/UL/CSA compliant
| Product ID | LP2K1210BD |
| Brand | Schneider Electric |
| Range / Series | TeSys K |
| Product Type | Reversing Contactor |
| Device Short Name | LP2K |
| GTIN / EAN | 03389110791105 |
| Application | Motor control, resistive load |
| Utilisation Category | AC-3, AC-3e, AC-4, AC-1 |
| Poles / Contacts | 3 NO power poles + 1 NO auxiliary |
| Rated Operational Current (Ie) | 12 A (≤ 440 V AC, AC-3/AC-3e) |
| Rated Operational Voltage (Ue) | ≤ 690 V AC 50/60 Hz |
| Control Circuit Voltage (Uc) | 24 V DC (0.8…1.15 Uc operational) |
| Control Circuit Type | DC standard |
| Motor Power (AC-3) | 3 kW @ 230 V | 5.5 kW @ 415 / 440 V | 4 kW @ 690 V |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Thermal Current (Ith) | 20 A (power), 10 A (signalling) |
| Making Capacity | 144 A AC (power) |
| Short-Time Withstand Current (Icw) | 115 A / 1 s (50 °C) |
| Associated Fuse Rating | 25 A gG (≤ 440 V) |
| Coil Inrush / Hold Power | 3 W / 3 W |
| Terminal Type | Screw-clamp, 0.34–4 mm² |
| Mounting | DIN-rail or plate |
| Interlocking Type | Mechanical (pre-assembled) |
| Operating Time | 30–40 ms energisation, 10 ms de-energisation |
| Mechanical Durability | 5 million cycles |
| Electrical Durability | 1.3 million cycles (12 A, AC-3) |
| Maximum Operating Rate | 3600 cycles/hour |
| Protection Degree | IP20 |
| Ambient Temp (Op.) | -25…+50 °C |
| Storage Temp | -50…+80 °C |
| Altitude (max) | 2000 m without derating |
| Dimensions (H × W × D) | 58 × 90 × 57 mm |
| Net Weight |
