Schneider LC1D258M7C Contactor, Coil Voltage AC 220V – Pack of 2

Schneider Electric LC1D258M7C Contactor (Pack of 2)

Manufacturer
Schneider Electric

Key Features
• 3-pole AC contactor for motor control and switching
• 220 VAC ±10 % coil voltage (50/60 Hz)
• 258 A AC-3 rated operational current at 400 VAC
• Silver-nickel main and auxiliary contacts for high endurance
• Integrated arc chute for reliable interruption
• DIN-rail (35 mm) or panel mounting

Electrical Specifications
• Utilization Category: AC-3 (motor starting)
• Rated Insulation Voltage (Ui): 690 VAC
• Rated Impulse Withstand Voltage (Uimp): 6 kV (1.2/50 μs)
• Coil Power Consumption: 25 VA (50 Hz) / 27 VA (60 Hz)
• Electrical Durability (AC-3, rated load): 200 × 10³ operations

Mechanical Data
• Terminals: Screw-clamp
– Solid conductors: 1.5 – 50 mm²
– Flexible conductors: 1.5 – 35 mm²
• Protection Degree: IP20 (front)
• Housing Material: Thermoset plastic / polycarbonate
• Operating Temperature: –25 °C to +60 °C
• Storage Temperature: –40 °C to +85 °C

Standards & Compliance
• IEC 60947-4-1, EN 60947-4-1
• UL 508, CSA C22.2 No 14
• CE, CCC, RoHS, REACH

Pack Contents
• 2 × LC1D258M7C Contactor (220 VAC coil)
