Schneider Electric LC1D258F7C TeSys Deca Contactor, 4P (2NO+2NC), 40A, 110V AC 50/60Hz Coil – Pack of 2
Regular price
$70.00 USD
Regular price
Sale price
$70.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview: The Schneider Electric LC1D258F7C is a TeSys Deca series 4-pole contactor designed for resistive loads (AC-1). It features a combination of 2 normally open (NO) and 2 normally closed (NC) power contacts, rated for 40A at up to 440V AC. The device is operated by a 110V AC 50/60Hz coil and utilizes screw terminals for secure connections.
Key Features:
- Utilisation Category: AC-1 for resistive loads.
- High Electrical Durability: 1.4 million cycles at 40A AC-1.
- Robust Mechanical Design: 15 million mechanical cycles.
- Wide Operating Temperature: -40°C to +60°C.
- Integrated Auxiliary Contacts: 1 NO + 1 NC mechanically linked type.
- Comprehensive Safety Certifications: CCC, CE, UKCA.
- Green Premium Product: Compliant with REACh, RoHS, and free of SVHC.
| Product ID | LC1D258F7C |
| Brand | Schneider Electric |
| Series | TeSys Deca |
| Product Type | Contactor |
| Poles & Contact Composition | 4P (2 NO + 2 NC) |
| Rated Operational Current (Ie) | 40 A (at ≤440 V AC, AC-1) |
| Rated Operational Voltage (Ue) | ≤ 690 V AC 25...400 Hz; ≤ 300 V DC |
| Control Circuit Voltage (Uc) | 110 V AC 50/60 Hz |
| Utilisation Category | AC-1 |
| Conventional Free Air Thermal Current (Ith) | 40 A (at 60°C) for power circuit |
| Rated Short-Time Withstand Current (Icw) | 240 A at 40°C for 10 s (power circuit) |
| Electrical Durability | 1.4 Mcycles (40 A AC-1 at Ue ≤ 440 V) |
| Mechanical Durability | 15 Mcycles |
| Inrush Power | 70 VA (cos φ 0.75 at 20°C) |
| Hold-in Power Consumption | 7.5 VA (60 Hz, cos φ 0.3 at 20°C) |
| Auxiliary Contacts | 1 NO + 1 NC (mechanically linked) |
| Terminal Type | Screw clamp (Control); Connector/Screw clamp (Power) |
| Tightening Torque (Power Circuit) | 1.8 N.m |
| Mounting | Plate or Rail |
| IP Protection Degree | IP2X (front face) |
| Operating Ambient Temperature | -40°C to +60°C |
| Dimensions (H x W x D) | 91 x 45 x 99 mm |
| Net Weight | 0.425 kg |
| Standards | GB 14048.4, IEC 60947-4-1 |
| Certifications | CCC, CE, UKCA |
| Sustainable Offer | Green Premium product, REACh & RoHS compliant |
