Schneider Electric GV2ME01 TeSys Deca Motor Circuit Breaker, 0.1–0.16 A, 100 kA Icu, 3-Pole
Regular price
$30.00 USD
Regular price
Sale price
$30.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview
Schneider Electric TeSys Deca GV2ME01 is a 3-pole thermal-magnetic motor circuit breaker/manual starter that delivers dependable protection and control for motors up to 0.16 A. With a high breaking capacity of 100 kA at up to 690 V AC, phase-failure sensitivity, and push-button operation, it clips directly onto 35 mm DIN-rail or mounts on a panel via an adaptor plate.
- Thermal-magnetic trip unit with 0.1…0.16 A adjustment
- 100 kA Icu breaking capacity (230…690 V AC)
- Push-button control; suitability for isolation
- Phase-loss protection, Category A, AC-3 utilisation
- Compact 45 mm (W) × 89 mm (H) × 78.5 mm (D), IP20
- Mechanical & electrical durability: 100 000 cycles each
| Product ID | GV2ME01 |
| Brand | Schneider Electric |
| Range | TeSys Deca |
| Series / Family | TeSys GV2 |
| Device short name | GV2ME |
| Product type | Motor circuit breaker / manual starter |
| Trip unit technology | Thermal-magnetic |
| Poles | 3P |
| Thermal adjustment range | 0.1…0.16 A |
| Magnetic tripping current | 1.93 A |
| Breaking capacity Icu | 100 kA @ 230–690 V AC |
| Service breaking capacity Ics | 100 % Icu (230–690 V AC) |
| Rated operational voltage Ue | 690 V AC 50/60 Hz |
| Rated insulation voltage Ui | 690 V AC |
| Rated impulse withstand voltage Uimp | 6 kV |
| Utilisation categories | Category A, AC-3, AC-3e |
| Phase-failure sensitivity | Yes |
| Control type | Push-buttons (Start/Stop) |
| Suitability for isolation | Yes (IEC 60947-1) |
| Mechanical durability | 100 000 cycles |
| Electrical durability | 100 000 cycles @ AC-3 415 V In |
| Mounting | 35 mm DIN-rail (clip); panel (with adaptor) |
| Terminal type & capacity | Screw clamp, 1–6 mm² solid / 1.5–6 mm² flex |
| Tightening torque | 1.7 N·m |
| Width | 45 mm (1.8 in) |
| Height | 89 mm (3.5 in) |
| Depth | 78.5 mm (3.09 in) |
| Net weight | 0.26 kg |
| IP rating | IP20 (IEC 60529) |
| IK rating | IK04 |
| Operating temperature | −20…60 °C (−4…140 °F) |
| Storage temperature | −40…80 °C (−40…176 °F) |
| Shock resistance | 30 Gn / 11 ms |
| Vibration resistance | 5 Gn, 5–150 Hz |
| Altitude limit | ≤ 2000 m |
| Standards | IEC 60947-2, IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1 |
| Certifications | CCC, UL, CSA, EAC, ATEX, Lloyd’s, BV, RINA, DNV-GL, UKCA |
| GTIN | 3389110342925 |
| Warranty | 18 months |
