Schneider Electric LXM23DU07M3X Lexium 23 Motion Servo Drive — Single-Phase 200–255 VAC Supply, 750 W Output, Integrated I/O — Compact Servo Drive

Product overview The Schneider Electric LXM23DU07M3X is a Lexium 23 series compact motion servo drive delivering 750 W continuous output power from a single-phase 200–255 VAC supply. Designed for precise single-axis motion control, it includes integrated I/O for straightforward machine integration and is suited to OEMs, packaging, robotics and small automated systems.

Key specifications

• Manufacturer: Schneider Electric (Lexium 23 series)
• Model: LXM23DU07M3X
• Supply voltage: Single-phase 200–255 VAC (nominal)
• Rated output power: 750 W (0.75 kW)
• Drive family: Lexium 23 motion servo drive
• Integrated I/O: Onboard I/O for control and machine interfacing (refer to official datasheet for detailed pinout and I/O functions)
• Form factor: Compact servo drive for panel or machine mounting
• Typical feedback/communication: Supports standard servo motor feedback types and control interfaces used in the Lexium 23 family (confirm encoder type and communication protocol in the datasheet)

Features and benefits

• 750 W continuous power in a compact footprint ideal for mid-range single-axis applications.
• Single-phase 200–255 VAC input allows deployment where three-phase supply is unavailable.
• Integrated I/O reduces external wiring and simplifies system architecture for OEMs and machine builders.
• Part of Schneider Electric’s Lexium ecosystem — simplifies matching with compatible motors, cables and configuration tools.
• Designed for accurate position, speed and torque control in packaging, conveyors, robotics and small machine tools.

Typical applications

• Packaging machinery, assembly equipment and conveyor segments
• Robotics, pick-and-place units and single-axis actuators
• OEM machines requiring compact servo drives with onboard I/O
• Retrofit projects where single-phase power and a compact drive are required

Installation and commissioning notes

• Install and wire per Schneider Electric installation instructions and applicable local electrical codes.
• Verify motor compatibility (power, torque, encoder type) and confirm parameterization requirements using the official Lexium 23 documentation.
• Confirm thermal management and cooling recommendations to avoid derating in enclosed or high-temperature installations.
• Use Schneider Electric configuration and commissioning tools for tuning, diagnostics and firmware management.

Documentation and support

• For complete electrical ratings, I/O pinout, protection, braking resistor requirements and firmware/communication details, consult the official Schneider Electric Lexium 23 datasheet and user manual for model LXM23DU07M3X.
• Follow Schneider Electric recommendations for cabling, grounding and EMC mitigation to ensure reliable operation.
