Schneider Electric LXM23DU04M3X Lexium 23 Motion Servo Drive — Single-Phase 200–255 VAC Supply, 400 W Output, Integrated I/O — Compact Servo Drive

Product overview The Schneider Electric LXM23DU04M3X is a Lexium 23 series motion servo drive engineered for compact servo applications requiring precise motion control. It accepts a single-phase 200–255 VAC supply and delivers 400 W continuous output power. The unit includes integrated I/O for straightforward machine integration and is designed for OEMs, packaging, robotics and small servo axis control.

Key specifications

• Manufacturer: Schneider Electric (Lexium 23 series)
• Model: LXM23DU04M3X
• Supply voltage: Single-phase 200–255 VAC (nominal)
• Rated output power: 400 W (0.4 kW)
• Drive family: Lexium 23 motion servo drive
• Integrated I/O: Onboard input/output for motion control and machine integration (refer to official datasheet for pinout and I/O details)
• Form factor: Compact servo drive for panel or machine-mount applications
• Typical communication/feedback: Supports standard servo motor feedback and control interfaces used in Lexium 23 family (confirm encoder/type in official documentation)

Features and benefits

• Compact design with 400 W power rating for space-constrained machines and single-axis servo control.
• Wide single-phase AC input (200–255 VAC) suitable for many regional supplies without three-phase infrastructure.
• Integrated I/O reduces external I/O modules and simplifies wiring for OEMs and machine builders.
• Part of Schneider Electric Lexium ecosystem — simplifies matching motors, cables and software tools for optimized performance.
• Designed for precise position, speed and torque control in small machinery and automation applications.

Typical applications

• Packaging machines, lab automation and small handling systems
• Robotics, cobots and single-axis motion control
• OEM machines requiring compact, integrated servo solutions
• Retrofits where single-phase supply and compact footprint are needed

Installation and commissioning notes

• Install and wire the drive according to Schneider Electric installation instructions and local electrical codes.
• Verify the motor and feedback device compatibility (encoder type, wiring and parameterization) using official Lexium 23 documentation.
• Confirm thermal dissipation and cooling requirements in the datasheet to avoid derating in enclosed installations.
• Use Schneider Electric configuration and commissioning tools (refer to product manuals) for tuning, parameter setup and diagnostics.

Documentation and support

• For complete electrical ratings, I/O pinout, protection, brake resistor requirements and firmware/communication details, consult the official Schneider Electric Lexium 23 datasheet and user manual for model LXM23DU04M3X.
• Follow Schneider Electric recommendations for cabling, filtering and grounding to ensure EMC compliance and reliable operation.
