Schneider Electric LXM23DU01M3X Lexium 23 Motion Servo Drive — Single-Phase 200–255 VAC Supply, 0.1 kW (100 W) Output, Integrated I/O — Compact Servo Drive

Product overview The Schneider Electric LXM23DU01M3X is a Lexium 23 series compact motion servo drive delivering 0.1 kW (100 W) continuous output from a single-phase 200–255 VAC supply. Designed for precise single-axis motion control in space-constrained machines, the unit integrates I/O to simplify wiring and accelerate machine integration. It is intended for OEMs, machine builders and automation applications requiring low-power, high-precision drives.

Key specifications

• Manufacturer: Schneider Electric
• Model: LXM23DU01M3X
• Supply voltage: Single-phase 200–255 VAC (nominal)
• Rated output power: 0.1 kW (100 W) continuous
• Drive family: Lexium 23 motion servo drive
• Integrated I/O: Onboard inputs and outputs for direct machine interfacing (consult official datasheet for pinout and signal definitions)
• Form factor: Compact servo drive for panel or machine mounting
• Compatibility: Designed for use with Lexium 23 motors and compatible feedback devices — verify encoder type and connector in Schneider Electric documentation

Features and benefits

• Compact 0.1 kW drive ideal for low-inertia axes, feeders, small conveyors, pick-and-place and precision positioning tasks.
• Single-phase 200–255 VAC input enables operation where three-phase supply is not available.
• Integrated I/O reduces external component needs, simplifying wiring and saving cabinet space.
• Part of the Lexium ecosystem for simplified motor/drive pairing, commissioning and technical support.
• Provides precise position, speed and torque control for a variety of light-duty automation applications.

Typical applications

• Small packaging machines, labeling and feeder systems
• Pick-and-place heads, gantry axes and cobot assist axes
• Laboratory automation, test benches and light assembly equipment
• OEM machines and retrofits where single-phase supply and compact motion control are required

Installation and commissioning notes

• Install and wire per Schneider Electric installation instructions and applicable local electrical codes.
• Confirm motor compatibility (power, torque, encoder type) and consult the official Lexium 23 documentation for parameter settings and wiring.
• Ensure adequate ventilation and thermal management to avoid drive derating in enclosed spaces.
• Use Schneider Electric configuration and commissioning tools for tuning, diagnostics and firmware updates.
• Follow recommended EMC, grounding and cabling practices for reliable operation.

Documentation and support

• For complete electrical ratings, I/O pinout, protection features, braking resistor requirements and communication/firmware details, consult the official Schneider Electric Lexium 23 LXM23DU01M3X datasheet and user manual.
