Schneider Electric Lexium BCH1001O12A1C Servo Motor, 20-bit Encoder, 1.0 kW, O-frame 100 mm, Keyed Shaft, No Oil Seal, Straight Connector

$450.00 USD
$450.00 USD
Sale Sold out
Shipping calculated at checkout.

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

Visa Mastercard PayPal Apple Pay Google Pay American Express
TECHNICAL DATASHEET PDF

Overview: The Schneider Electric BCH1001O12A1C is a discontinued servo motor from the BCH series, compatible with the Lexium 23 Plus drive system. It is a 1 kW, single-phase motor designed for high-performance motion control applications, featuring a 20-bit incremental encoder for precise positioning and a keyed shaft for secure torque transmission.

Key Features:

  • High-resolution 20-bit incremental encoder for accurate feedback.
  • Designed for compatibility with Lexium 23 Plus servo drives.
  • Natural convection cooling for simplified installation.
  • Asian standard (100 mm) flange mounting.
  • Keyed shaft (22 mm diameter) for reliable mechanical connection.
Product ID / MPN BCH1001O12A1C
Brand Schneider Electric
Product Type Servo Motor
Compatible Main Range Lexium 23 Plus
Continuous Power 1 kW
Rated Supply Voltage [Us] 220 V
Network Number of Phases Single phase
Continuous Stall Current 7.3 A
Maximum Mechanical Speed 5000 rpm
Torque Constant 0.43 N.m/A
Back EMF Constant 16.8 V/krpm at 20 °C
Rotor Inertia 2.65 kg.cm²
Stator Resistance 0.4 Ohm at 20 °C
Stator Inductance 3.62 mH at 20 °C
Stator Electrical Time Constant 9.3 ms at 20 °C
Feedback Type 20 bits incremental encoder
Holding Brake Without
Shaft End Keyed
Shaft Diameter 22 mm
Shaft Length 37 mm
Key Width 8 mm
Mounting Support Asian standard flange
Motor Flange Size 100 mm
Maximum Radial Force Fr 490 N
Maximum Axial Force Fa 98 N
Centring Collar Diameter 95 mm
Centring Collar Depth 5 mm
Number of Mounting Holes 4
Mounting Holes Diameter 9 mm
Circle Diameter of Mounting Holes 115 mm
Distance Shaft Shoulder-Flange 37 mm
Length (without brake) 153.5 mm
Net Weight 4.3 kg
IP Degree of Protection IP40
Ambient Air Temperature for Operation 0…40 °C
Type of Cooling Natural convection
Warranty 18 months
Product Status Discontinued (Service only)
