• Schneider Backplane Schneider Electric BMXXBP1200 Modicon X80 Backplane — 12‑Slot X‑Bus Rack, Panel/Mounting‑Plate, DIN‑Rail Compatible, 503.2×103.7×19 mm, 1.27 kg, IP20
1 1

Schneider Electric BMXXBP1200 Modicon X80 Backplane — 12‑Slot X‑Bus Rack, Panel/Mounting‑Plate, DIN‑Rail Compatible, 503.2×103.7×19 mm, 1.27 kg, IP20

$220.00 USD
$220.00 USD
Sale Sold out
Shipping calculated at checkout.

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

Visa Mastercard PayPal Apple Pay Google Pay American Express
TECHNICAL DATASHEET PDF

Overview
The Schneider Electric BMXXBP1200 is a 12-slot backplane designed for the Modicon X80 programmable logic controller (PLC) system. It provides the electrical and mechanical backbone for connecting a BMXP34 processor, BMXCPS power supply, and various I/O or application modules. Engineered for panel or mounting plate installation, this backplane features a compact depth and supports operation in industrial environments with an IP20 rating.

Key Features

  • 12-slot capacity for comprehensive system expansion.
  • Compatible with BMXP34 processor, BMXCPS power supply, and X80 I/O modules.
  • Low power consumption of only 0.17 W.
  • Designed for secure mounting via 4 M4/M5/M6 screws on a panel or Telequick mounting plate.
  • Complies with key industrial standards including UL, CSA, and IEC 61131-2.
  • Features a single XBE connector for expansion module connectivity.

Technical Specifications

Product ID BMXXBP1200
Range of product Modicon X80
Product or component type Backplane
Number of slots 12
Product compatibility BMXP34 processor, BMXCPS power supply, I/O module, Specific application module
Power consumption 0.17 W
Electrical connection 1 connector (XBE) expansion module
Fixing mode By 4 M4/M5/M6 screws, mounting on panel
By 4 M4/M5/M6 screws, mounting on mounting plate
Height 103.7 mm
Width 503.2 mm
Depth 19 mm
Net weight 1.27 kg
IP degree of protection IP20
Ambient air temperature for operation 0...60 °C
Relative humidity 10...95 % without condensation
Product certifications CE, UL, CSA, RCM, EAC, UKCA, Merchant Navy
Standards EN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201, CSA C22.2 No 61010-2-201, IACS E10, EN/IEC 61000-6-5, EN/IEC 61850-3
