Schneider Electric BMXXBP0800 Modicon X80 Backplane — 8‑Slot Rack (Processor/I/O/Comm), Panel/Plate/DIN‑Rail Mountable, IP20
Regular price
$260.00 USD
Regular price
Sale price
$260.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview: The Schneider Electric BMXXBP0800 is an 8-slot backplane for the Modicon X80 automation platform, designed to house and interconnect processors, power supplies, and I/O modules. It offers versatile mounting options including panel, mounting plate, or standard 35mm DIN rail installation. This robust backplane provides the essential bus structure for system expansion and reliable communication between modules in industrial control applications.
Key Features:
- 8-slot backplane for Modicon X80 system expansion.
- Multiple mounting options: panel, mounting plate, or 35mm symmetrical DIN rail.
- Compatible with BMXP34 processors, BMXCPS power supplies, and all X80 I/O modules.
- Compact design with integrated bus structure.
- Robust construction for industrial environments.
| Product ID / MPN | BMXXBP0800 |
| EAN / GTIN | 3595863909012 |
| Brand | Schneider Electric |
| Range / Series | Modicon X80 |
| Product Type | Backplane |
| Number of Slots | 8 |
| Product Compatibility | BMXP34 processor, BMXCPS power supply, I/O module, Specific application module |
| Power Consumption | 2.21 W |
| Electrical Connection | 1 connector (XBE) expansion module |
| Fixing Mode | By 4 M4/M5/M6 screws panel, By 4 M4/M5/M6 screws mounting plate, By clips 35 mm symmetrical DIN rail |
| Height | 4.08 in (103.7 mm) |
| Width | 14.7 in (372.8 mm) |
| Depth | 0.7 in (19 mm) |
| Net Weight | 2.09 lb (0.95 kg) |
| IP Degree of Protection | IP20 |
| Operating Temperature | 32...140 °F (0...60 °C) |
| Relative Humidity | 10...95 % without condensation |
| Product Certifications | CE, UL, CSA, RCM, EAC, UKCA, Merchant Navy |
