Schneider Electric BMXART0814 Modicon X80 Analog Isolated Low‑Level Input Module — 8 Channels, ±40 mV/±80…±1.28 V, 15‑bit + sign, Isolated, IP20

$135.00 USD
$135.00 USD
Sale Sold out
Shipping calculated at checkout.

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

Visa Mastercard PayPal Apple Pay Google Pay American Express
TECHNICAL DATASHEET PDF

Schneider Electric BMXART0814 is an isolated, low-level analog input module for Modicon X80 PAC systems. It offers eight individually isolated channels capable of measuring micro-volt to milli-volt signals, resistance, RTD, and thermocouple sensors with 16-bit sigma-delta conversion. Designed for demanding industrial environments, the module features built-in digital filtering, wide sensor support, and on-board diagnostics LEDs.

Key Features

  • 8 isolated low-level analog inputs
  • Voltage ranges: ±40 mV, ±80 mV, ±160 mV, ±320 mV, ±640 mV, ±1.28 V
  • Resistance measurement: 400 Ω / 4 kΩ, 2-, 3- or 4-wire
  • RTD support: Pt100/Pt1000, Ni100/Ni1000, Cu10 (-100…+450 °C)
  • Thermocouple support: Types B, E, J, K, L, N, R, S, T, U (-270…+1820 °C)
  • 16-bit sigma-delta A/D conversion with 15-bit + sign resolution
  • First-order digital filter; 200 ms (TC) / 400 ms (RTD) read cycle
  • Common-mode rejection 120 dB; differential-mode rejection 60 dB (50/60 Hz)
  • Diagnostics LEDs for RUN, channel status, ERR, I/O
Product ID BMXART0814
Brand Schneider Electric
Range Modicon X80
Product type Analog isolated low-level input module
Analogue inputs 8 channels
Isolation between channels Isolated
Input level Low level
Voltage input ranges ±40 mV, ±80 mV, ±160 mV, ±320 mV, ±640 mV, ±1.28 V
Resistance measurement 400 Ω / 4 kΩ (2, 3, 4-wire)
RTD ranges -100…+260 °C Cu10; -100…+450 °C Pt100/Pt1000
Thermocouple types B, E, J, K, L, N, R, S, T, U
A/D conversion Sigma-delta 16 bit
Resolution 15 bits + sign
Digital filter First-order
Read cycle time 400 ms (RTD) / 200 ms (TC)
CMR / DMR 120 dB / 60 dB @ 50/60 Hz
Cold junction compensation External Pt100 probe
Electrical connection 2× 40-way connectors
Current consumption 150 mA @ 3.3 V DC; 50 mA @ 24 V DC
MTBF 900 000 h
Status LEDs RUN (green), ERR (red), I/O (red), 1 per channel (green)
Net weight 0.165 kg
Operating temperature 0…60 °C
Storage temperature -40…85 °C
Relative humidity 5…95 % (55 °C, non-condensing)
Vibration resistance 3 g
Shock resistance 30 g
Operating altitude 0–2000 m (5000 m with derating)
IP rating IP20
Standards IEC 61131-2, IEC 61000-6-2/-6-4, EN 61010-2-201
Certifications CE, UL, CSA, EAC, RCM, Merchant Navy
Warranty 18 months
