Schneider Electric BCH1303N12A1C BCH Series Servo Motor — 1.5 kW, 220 VAC Single-Phase, 3000 rpm Max, Keyed Shaft 22 mm (8 mm Key), 20-bit Incremental Encoder, No Brake, IP40
Regular price
$550.00 USD
Regular price
Sale price
$550.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview
The Schneider Electric BCH1303N12A1C is a BCH series servo motor compatible with Lexium 23 Plus drives. This 1.5kW motor delivers a continuous stall current of 8.3A, achieves a maximum speed of 3000 RPM, and features a 22mm keyed shaft. It is equipped with a high-resolution 20-bit incremental encoder for precise positioning and is rated IP40 for protection against solid objects.
Key Features
- Compatible with Lexium 23 Plus servo drives.
- Rated for 220V single-phase supply.
- Continuous output power of 1.5 kW with a stall current of 8.3 A.
- High maximum mechanical speed of 3000 RPM.
- Equipped with a high-precision 20-bit incremental encoder.
- 22mm diameter keyed shaft with an 8mm key width.
- Features a 130mm Asian standard mounting flange.
- Natural convection cooling design.
- IP40 degree of protection.
- Designed without a holding brake or oil seal.
| Product ID | BCH1303N12A1C |
| Brand | Schneider Electric |
| Product Type | Servo Motor |
| Compatible Range | Lexium 23 Plus |
| Rated Supply Voltage | 220 V |
| Maximum Speed | 3000 rpm |
| Continuous Stall Current | 8.3 A |
| Continuous Power | 1.5 kW |
| Shaft Type | Keyed |
| Shaft Diameter | 22 mm |
| Key Width | 8 mm |
| Feedback Type | 20 bits incremental encoder |
| Holding Brake | Without |
| Motor Flange Size | 130 mm |
| Torque Constant | 0.87 N.m/A |
| Rotor Inertia | 11.18 kg.cm² |
| Motor Length (without brake) | 167.5 mm |
| Net Weight | 7.5 kg |
| IP Rating | IP40 |
| Operating Temperature |
