Schneider Electric Altivar ATV61HD45N4Z VFD, 60 HP (45 kW), 3-Phase 380-480V, IP20, Modbus, CANopen

$2,800.00 USD
$2,800.00 USD
Sale Sold out
Shipping calculated at checkout.

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

Visa Mastercard PayPal Apple Pay Google Pay American Express
TECHNICAL DATASHEET PDF

Overview: The Schneider Electric ATV61HD45N4Z is a discontinued variable speed drive (VSD) from the Altivar 61 series, designed for demanding industrial applications such as pumping and ventilation. This 45 kW (60 hp) drive operates on a 380-480V, 3-phase supply and features a comprehensive set of control modes, including sensorless flux vector control for high performance. It is housed in a chassis with an IP20 rating on the upper section and includes multiple communication and I/O expansion options via optional cards.

Key Features:

  • High Power Rating: 45 kW (60 HP) for driving large three-phase motors.
  • Wide Voltage Range: Operates from 380V to 480V AC, 3-phase, with a tolerance of -15% to +10%.
  • Advanced Motor Control: Supports Voltage/Frequency (U/f), Sensorless Flux Vector Control, and Synchronous Motor control profiles.
  • Flexible Communication: Built-in Modbus and CANopen ports, with support for numerous optional communication cards (Profibus DP, EtherNet/IP, DeviceNet, etc.).
  • Integrated Safety: Features a Safe Torque Off (STO) input (PWR) for safety-related shutdowns.
  • Robust Design: Conforms to multiple industrial standards (IEC, UL, CSA) and offers various IP protection levels depending on installation (IP20, IP21, IP41, IP54).
Product ID / Article Code ATV61HD45N4Z
EAN / GTIN 3389119205313
Brand Schneider Electric
Series Altivar 61
Product Type Variable Speed Drive
Motor Power 45 kW
Horsepower 60 hp
Supply Voltage 380...480 V AC
Supply Phases 3
Line Current (380V) 104 A
Line Current (480V) 85 A
Continuous Output Current (12 kHz, 380V) 94 A
Continuous Output Current (12 kHz, 460V) 77 A
Output Frequency Range 0.1…500 Hz
Nominal Switching Frequency 12 kHz
Switching Frequency Range 1...16 kHz adjustable
Control Modes Voltage/frequency ratio (2 & 5 pts), Sensorless Flux Vector, Synchronous Motor control
Analog Inputs 2 (AI1: +/-10V, AI2: 0-20mA / 0-10V)
Analog Outputs 1 (AO1: 0-20mA / 0-10V)
Discrete Inputs 7 programmable (LI1...LI6, PWR)
Relay Outputs 2 configurable (R1: NO/NC, R2: NO)
Communication Ports Modbus (RJ45 front & terminal), CANopen (SUB-D 9)
Degree of Protection (IP) IP20 (upper part), IP21, IP41, IP54 (lower part)
Operating Temperature -10…50 °C (14…122 °F) without derating; 50…60 °C (122…140 °F) with derating
Storage Temperature -25…70 °C (-13…158 °F)
Relative Humidity 5…95 % without condensation
Operating Altitude ≤ 1000 m (3280 ft) without derating; 1000-3000 m with derating
Dimensions (W x H x D) 320 x 630 x 290 mm (12.6 x 24.8 x 11.4 in)
Net Weight 44 kg (97 lb)
Standards IEC 61800-3, IEC 61800-5-1, UL, CSA, GOST, CE
Status Discontinued (Jan 1, 2017). End-of-service: Dec 31, 2025.
