The ProSoft Technology MVI56E-SIE is an advanced in-chassis module designed specifically for Rockwell Automation ControlLogix® processors, enabling seamless and robust communication with Siemens Industrial Ethernet devices. This module acts as a powerful bridge, allowing ControlLogix controllers to efficiently exchange data with Siemens S7-300 and S7-400 PLCs over a standard Ethernet network using TCP/IP protocol. It provides a high-performance, single-slot solution for integrating Siemens-based systems into a ControlLogix architecture, crucial for mixed-vendor industrial automation environments.

Manufacturer Information:

• Manufacturer: ProSoft Technology
• Part Number (Model): MVI56E-SIE
• Product Series: MVI56E (Enhanced Communication Module for ControlLogix)
• Product Type: In-Chassis Communication Module / Siemens Industrial Ethernet Module
• Compatibility: Rockwell Automation ControlLogix® series processors (e.g., L6x, L7x, L8x as applicable).
• Function: Enables Siemens Industrial Ethernet TCP/IP communication for ControlLogix.
• Key Features & Specifications:
  • Processor Compatibility: Designed as an in-chassis module for the ControlLogix platform, it slides directly into a ControlLogix chassis.
  • Siemens Connectivity: Supports communication with Siemens S7-300 and S7-400 PLCs.
  • Protocol: Utilizes TCP/IP for industrial Ethernet communication. This implies support for standard Ethernet physical layers (e.g., 10/100 Mbps).
  • Data Exchange: Facilitates the exchange of various data types between ControlLogix and Siemens PLCs, including data blocks, I/O, and status information.
  • Programming: Configuration through Rockwell Automation's RSLogix 5000/Studio 5000 environment, typically using custom ADD-ON Instructions (AOIs) and a dedicated configuration utility.
  • Memory: Built-in memory for configuration and data buffering, enhancing communication reliability.
  • Diagnostic Features: Provides comprehensive diagnostic data that can be monitored from the ControlLogix processor, helping with troubleshooting and system health checks.
  • Performance: High-speed data throughput to meet demanding industrial control requirements.
  • Physical: Single-slot ControlLogix chassis module. Front panel indicators for status and health.
• Application: Ideal for integrating diverse automation systems where:
  • Rockwell ControlLogix is the primary control platform.
  • Siemens S7-300/400 PLCs are present in various parts of a plant (e.g., different legacy machines, packaged units from other vendors).
  • Reliable, high-speed data exchange between these platforms is required for supervisory control, data acquisition (SCADA), and manufacturing execution systems (MES).
  • Existing Ethernet infrastructure is utilized for communication.
• Benefits:
  • Reduces the need for complex gateway devices or custom programming.
  • Leverages existing Ethernet infrastructure.
  • Provides a native ControlLogix integration experience.
  • Enhances interoperability in heterogeneous industrial networks.
