Parker T6CM B10 3L00 C5 Single Vane Pump, 2.08 in³/rev, SAE "C" Splined Shaft, Left-Hand Rotation, Phosphate Ester Seal

The Parker Denison T6CM B10 3L00 C5 Single Vane Pump is a high-performance, robust hydraulic pump specifically designed for demanding mobile applications where phosphate ester fluids are utilized. As a core offering within Parker's renowned T6CM series, this single vane pump provides exceptional efficiency, reliability, and an extended service life in a compact footprint. This model is engineered for precision and durability, ensuring optimal performance across various challenging operational environments, with a particular focus on compatibility with specialized hydraulic fluids.

Key Features:

• Precise Displacement: Features a B10 cam ring, providing a fixed displacement of 2.08 in³/rev (approximately 10.8 GPM at 1200 RPM/0 PSI). This precise flow rate ensures consistent and reliable hydraulic power for your system.
• SAE "C" Splined Shaft: Equipped with a durable SAE "C" Splined Shaft (Code 3), designed for robust power transmission and easy integration into drive systems.
• Left-Hand (Counter-Clockwise) Rotation: Configured for left-hand rotation (counter-clockwise when viewed from the shaft end), matching specific system requirements for directional operation.
• Phosphate Ester Fluid Compatibility (S5 Seal): Utilizes a specialized S5 seal material (Code C), explicitly engineered for superior compatibility and extended service life when operating with phosphate ester fluids such as Skydrol, Fyrquel, and other synthetic fire-resistant fluids. This ensures reliable performance in critical applications where fire resistance is paramount.
• Standard Porting: Features standard porting without reduction (Code 00), allowing for direct and efficient connection to hydraulic lines.
• High Pressure Performance: Capable of handling pressure ratings up to 4000 PSI (fluid type dependent). This robust capability enables the use of smaller, more cost-effective actuators, valves, and lines, while simultaneously promoting extended component life at reduced operating pressures.
• Superior Efficiency: Exhibits high volumetric (typically 94%) and mechanical (typically 94%) efficiency under load. This translates directly into improved productivity, less heat generation, and lower operational costs. The pump can operate efficiently at low speeds, down to 400 RPM, even at full pressure.
• Cartridge Design for Easy Service: Features an innovative cartridge design that allows for quick and easy replacement of serviceable elements in minutes. This minimizes downtime, reduces maintenance costs, and mitigates the risk of contamination. T6CM pumps are bi-rotational in principle, with rotation direction easily adjustable by repositioning the cam ring (though this specific model is configured for Left-Hand rotation).
• Reduced Noise Operation: Engineered with low noise levels to contribute to enhanced operator safety and acceptance in various work environments. The design minimizes pressure ripple (typically ± 29 PSI), further reducing piping noise and extending the lifespan of other circuit components.
• Broad Viscosity Acceptance: Operates reliably across a broad range of fluid viscosities, from 9240 to 60 SUS, facilitating optimal performance during cold start-ups and in hot running conditions. The balanced design effectively compensates for wear and temperature changes, ensuring consistent lubrication and mechanical efficiency.

Technical Specifications:

• Model: T6CM B10 3L00 C5
• Pump Type: Single Vane Pump
• Displacement: 2.08 in³/rev
• Shaft Type: Splined Shaft (SAE "C" Splined)
• Rotation: Left-Hand (Counter-Clockwise, viewed from shaft end)
• Porting Combination: Standard Porting without Port Reduction
• Seal Class: S5 (Special Seal) for Phosphate Esters (e.g., Skydrol, Fyrquel)
• Design Code: 5
• Maximum Operating Pressure: Up to 4000 PSI (dependent on fluid type).
• Speed Range: Typically 400 RPM to 2800 RPM (dependent on configuration and fluid properties).
• Fluids Compatibility: Specifically designed for Phosphate Ester Fluids (e.g., Skydrol, Fyrquel). Also compatible with petroleum-based anti-wear R&O fluids with appropriate seal changes.
• Fluid Cleanliness: Recommended contamination level of NAS 1638 Class 8 (or ISO 18/14) or better.
• Weight: Approximately 34.0 lbs
