OMRON D4N-212G Safety Limit Switch, 1NC/1NO, IP67 Protection, Adjustable Roller Lever

$25.00 USD
$25.00 USD
Sale Sold out
Shipping calculated at checkout.
Pack Size

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

Visa Mastercard PayPal Apple Pay Google Pay American Express
TECHNICAL DATASHEET PDF

The OMRON D4N-212G is a reliable safety limit switch featuring an adjustable roller lever actuator with a form lock mechanism. It delivers excellent performance with its snap-action operation and robust design.

Key Features:

  • Adjustable roller lever with a metal lever and resin roller
  • Snap-action mechanism for quick operation
  • 1NC/1NO contact configuration
  • IP67 rated for superior protection against dust and water
  • G1/2 conduit connection
  • Designed for general and micro load applications
Product ID D4N-212G
Operating Mechanism Snap action
Contact Form 1NC/1NO
Degree of Protection IP67
Operating Temperature -30 to 70 ℃
Ambient Humidity 95% RH max.
Operating Frequency 30 operations/min max.
Conduit Size G1/2
Durability 15,000,000 operations min.
Vibration Resistance 10 to 55 Hz, 0.75 mm single amplitude
Shock Resistance Destruction: 1000 m/s², Malfunction: 300 m/s²
