Nichicon UES1E220MEM Muse ES Series Audio Capacitor, 22uF 25V, Bi-Polar Radial Leaded - Pack of 20

The Nichicon UES1E220MEM is a high-performance bi-polar (non-polar) aluminum electrolytic capacitor from the prestigious "Muse" ES series. Specifically designed for premium acoustic applications, the Muse ES series is a favorite among audio engineers for its ability to deliver a transparent and neutral sound profile. Its bi-polar design allows for effective signal coupling and DC-blocking in audio circuits where polarity may reverse, ensuring high-fidelity performance in amplifiers, signal processors, and high-end consumer electronics.

Key Features

• Acoustic Optimization: Engineered specifically for high-quality audio equipment, providing superior sound resolution and depth compared to standard capacitors.
• Bi-Polar (Non-Polarized) Design: Specifically built to handle AC signals or circuits where the DC bias is unknown, eliminating the risk of polarity-related failure in the signal path.
• Compact Radial Form Factor: The 6.3x11mm dimensions and 2.5mm lead spacing allow for easy integration into high-density circuit board layouts.
• High Performance Stability: Features a low dissipation factor (0.16) and a very low leakage current of only 3 µA, preserving the purity of the audio signal.
• Rugged Reliability: Rated for operation in demanding environments ranging from -40°C to +85°C with a 1000-hour service life at maximum temperature.

Technical Specifications

• Manufacturer: Nichicon
• Series: Muse ES (UES)
• Capacitance: 22 µF
• Voltage Rating: 25V DC
• Tolerance: ±20% at 120Hz, 20°C
• Operating Temperature Range: -40°C to +85°C
• Termination Style: Radial Lead (Straight)
• Dimensions: 6.3 mm Diameter x 11 mm Length
• Lead Spacing: 2.5 mm
• Package Quantity: 20 Pieces
