Nichicon LKG1J103MESCAK Gold Tune Audio Grade Capacitor, 10000uF 63V, Snap-In, 35x50mm - Pack of 5

The Nichicon LKG1J103MESCAK is a premium "Gold Tune" (Grade II) aluminum electrolytic capacitor, specifically developed for high-fidelity audio applications. As part of Nichicon's LKG series, this snap-in component is engineered to provide superior acoustic characteristics, offering a balanced and transparent sound profile with powerful low-end response. It is an ideal choice for high-end audio power amplifiers and professional sound equipment where high energy storage and low resonance are essential.

Key Features

• Acoustic Optimization: Part of the legendary Gold Tune series, utilizing specialty materials and construction techniques to minimize vibration and enhance sound quality.
• High Energy Density: Features a high capacitance of 10000uF and a 63V rating, providing a stable and clean power reservoir for demanding audio circuits.
• High Ripple Current Handling: Rated at 4.8 A, allowing for efficient performance under high-load conditions and ensuring rapid transient response in audio signals.
• Secure Snap-In Design: Equipped with a standard 10mm lead spacing snap-in terminal, ensuring a rigid and secure mechanical connection to the PCB.
• Audiophile Construction: Housed in a 35mm x 50mm cylindrical can, this capacitor is designed for longevity and performance stability in high-performance power supply rails.

Technical Specifications

• Manufacturer: Nichicon
• Series: LKG Gold Tune (Grade II)
• Capacitance: 10000 µF
• Voltage Rating: 63V DC
• Tolerance: ±20% (120Hz, 20°C)
• Operating Temperature Range: -40°C to +85°C
• Ripple Current: 4.8 A
• Leakage Current: 2.38 mA (max)
• Body Dimensions: 35 mm Diameter x 50 mm Length
• Lead Spacing: 10 mm
• Mounting Style: Snap-In (2-pin)
• Component Weight: 66 g
• Package Quantity: 5 Pieces
