Mitsubishi FX3SA-20MT-CM PLC

Mitsubishi Electric FA-COM PLC: Main Unit FX3S-20MT-ES

Product Overview:

The Mitsubishi Electric FX3S-20MT-ES is a compact and efficient Programmable Logic Controller (PLC) designed for a variety of industrial automation applications. As part of the MELSEC-F Series, this main unit offers a blend of performance and ease of use.

Key Features:

• Program Memory: 16K Steps (EEPROM)
• Integrated Inputs: 12 Digital Inputs
• Integrated Outputs: 8 Transistor Outputs (Sink Logic)
• Expandability: Not Expandable

Technical Specifications:

• Type: FX3S
• Power Supply: 100-240 V AC
• Cycle Time:
  • LD (ns): 210
  • MOV (ns): 500
• Communication Ports:
  • USB: 1
  • RS-422: 1
• Power Consumption: 20 W
• Protection Class: IP10
• Ambient Temperature:
  • Minimum: 0°C
  • Maximum: 55°C

Additional Information:

• Series: MELSEC-F SERIES
• Local I/O Points: 20
• Buffer Battery: NO
