JiangHai CD138 Screw Terminal Electrolytic Capacitor, 5600µF 450V DC, 85°C Large Can - Pack of 18

The JiangHai CD138 series is a high-capacity screw terminal aluminum electrolytic capacitor designed for industrial applications requiring high reliability and high ripple current capability. Engineered for heavy-duty power electronics, this capacitor is ideal for use in frequency converters, uninterruptible power supplies (UPS), solar inverters, and professional power supply units. The large-can "bolt-on" design ensures a secure electrical connection and efficient heat dissipation in demanding environments.

Key Features

• High Capacitance and Voltage: Features a massive 5600µF storage capacity at 450V DC, providing excellent energy density for DC-link applications.
• Long Operational Life: The CD138 series is engineered for durability, offering stable performance over thousands of hours at its maximum rated temperature.
• Screw Terminal Design: Equipped with robust screw (bolt) terminals for low contact resistance and high vibration resistance, facilitating secure mounting in industrial cabinets.
• High Ripple Current Handling: Specially designed to manage significant ripple currents, making it suitable for high-power switching and filtering circuits.
• Safety Construction: Built with an integrated safety vent to protect against internal overpressure, ensuring safe operation within industrial systems.

Technical Specifications

• Manufacturer: JiangHai
• Series: CD138
• Capacitance: 5600µF
• Rated Voltage: 450V DC
• Tolerance: ±20%
• Operating Temperature: -40°C to +85°C
• Termination Type: Screw Terminals (Bolt-on)
• Dielectric: Aluminum Electrolytic
• Package Quantity: 18 Pieces
