HONGFA HFGA1/G-4H1D-U24 Safety Relay Module

HONGFA Contact Expansion Module HFGA1/G-4H1D-U24

A contact expansion module by HONGFA, designed to increase the number of available output contacts in a safety circuit. This module serves as an extension and can be used in conjunction with any HONGFA main safety relay module to provide additional normally open and normally closed contacts.

Key Features & Specifications:

• Brand: HONGFA
• Product Type: Contact Expansion Module
• Application: Increases the quantity of output contacts for a main safety relay module.
• Compatibility: Designed to be used with any HONGFA main safety relay module.
• Input Configuration: Receives signals via Single-Channel or Dual-Channel connection from the main module.
• Reset Function: Follows the reset logic (Automatic Start or Manual Start) of the connected main safety relay module.
• Outputs: 4 x Normally Open (N/O), 1 x Normally Closed (N/C) contacts.
• Terminals: Available with Pluggable Screw Terminals or Pluggable Spring-Cage Terminals (specify option when ordering).

Technical Data:

• Product Code: HFGA1/G-4H1D-U24
• Outputs: 4 N/O, 1 N/C
• Reset Type: Dependent on the main safety relay module (Automatic / Manual)
