General Electric (GE) Record Plus FDH36MC080GD — FD Frame 3‑Pole Molded Case Circuit Breaker, 80A, 690V, Magnetic‑Only (Instantaneous), Feed‑Thru Connection, 80 kA @ 415V AIC

Product overview The General Electric (GE) Record Plus FDH36MC080GD is a robust FD‑frame, 3‑pole molded case circuit breaker (MCCB) engineered for industrial power distribution and motor feeder protection. This FDH type unit provides magnetic‑only instantaneous protection with a feed‑through connection and high interrupting capacity for demanding short‑circuit environments.

Key specifications

• Manufacturer / Brand: General Electric (GE)
• Family / Series: Record Plus — FD Frame (FDH type)
• Part number: FDH36MC080GD
• Product type: Molded Case Circuit Breaker (MCCB) — FD frame
• Poles: 3‑pole (three‑phase)
• Nominal current rating: 80 A
• Rated voltage: 690 V (system voltage capability)
• Protection type: Magnetic‑Only (instantaneous trip)
• Trip function(s): I — Instantaneous
• Connection style: Feed‑Thru
• AIC / Short‑circuit interrupting capacity: 80 kA @ 415 V
• Weight: 4 lbs (approx.)
• Typical applications: Industrial distribution panels, motor feeders, service equipment where instantaneous magnetic protection and high short‑circuit rating are required

Features & benefits

• High AIC rating (80 kA @ 415 V) for robust interruption of large fault currents and improved system safety.
• Magnetic‑only instantaneous protection (I function) for fast clearing of short circuits without thermal trip delay—suitable for specific motor or fault protection schemes.
• Feed‑through connection simplifies downstream distribution wiring and reduces panel footprint.
• FD frame platform provides mechanical robustness and compatibility with Record Plus accessories and mounting systems.

Installation & safety notes

• Verify system voltage compatibility (rated to 690 V) and appropriate coordination with upstream/downstream protective devices.
• Magnetic‑only protection provides instantaneous trip action; ensure this characteristic matches application requirements since thermal/long‑time protection is not provided.
• Confirm mechanical mounting and feeder connection requirements per GE installation instructions.
• Use GE time‑current data and coordination charts when integrating into protective schemes.

Documentation & support

• For full technical data, trip curves, dimensional drawings, accessory options and installation procedures for FDH36MC080GD, consult the GE Record Plus FD frame datasheet and installation manual.
