EPCOS B43505-A9227-M7 400V 220µF Aluminum Electrolytic Capacitor
Regular price
$8.00 USD
Regular price
Sale price
$8.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
This EPCOS B43505-A9227-M7 is a high-performance, long-life aluminum electrolytic capacitor designed for demanding industrial power electronics. With a 400V DC rating and 220 µF capacitance, it is engineered for applications such as frequency converters, professional power supplies, and motor drives. The capacitor features a snap-in terminal design (M7, 4.5 mm short terminals) for secure PCB mounting, low ESR for high ripple current capability, and is built to pass stringent flammability tests. It offers a useful life of over 5,000 hours at 105°C under full rated conditions.
Key Features
- Long Useful Life grade, rated for >5,000 hours at 105°C.
- Low ESR design for outstanding ripple current capability.
- Snap-in terminals (4.5 mm) for secure PCB mounting.
- Fully insulated aluminum case (PVC).
- RoHS-compatible and passes needle flame test (IEC 60695-11-5).
- Designed for frequency converters and industrial power supplies.
Technical Specifications
| Product ID | B43505-A9227-M7 |
| Capacitance | 220 µF |
| Rated Voltage | 400 V DC |
| Series | B43505 |
| Terminal Type | Snap-In (4.5 mm, Short) |
| ESR (Typical @ 100 Hz, 20°C) | 40 mΩ |
| Ripple Current (IAC,R @ 105°C, 100 Hz) | 1.3 A |
| Case Dimensions (d x l) | 30 mm x 40 mm |
| Operating Temperature | -40°C to +105°C |
| Lifetime @ 105°C | > 5,000 hours |
