• ELECTRONICON ELECTRONICON E62.G10-202B20 2uf 2400VAC Capacitor
1 1

Electronicon E62.G10-202B20 E62 Series Heavy Duty Capacitor, 4000V DC / 2400V AC, 2.0µF

$150.00 USD
$150.00 USD
Sale Sold out
Shipping calculated at checkout.
Pack Size

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

Visa Mastercard PayPal Apple Pay Google Pay American Express
TECHNICAL DATASHEET PDF

The ELECTRONICON E62.G10-202B20 is a heavy-duty AC/DC film capacitor from the universal E62 series, designed for demanding power electronics applications. It features a hermetically sealed aluminum can filled with environmentally friendly plant oil and is optimized for high RMS currents, making it suitable for non-sinusoidal voltages, pulsed currents, damping, commutation, and AC filter circuits. The integrated break-action mechanism (BAM) ensures safe, controlled disconnection in case of overload.

Key Features

  • Heavy-duty AC capacitor for universal and high-current applications.
  • Hermetically sealed aluminum can with plant oil filling (standard).
  • Integrated overpressure protection (Break-Action Mechanism - BAM™).
  • Optimized for high RMS and surge currents (Imax: 16A, Î: 0.5kA).
  • Self-healing metallized polypropylene (MKP) dielectric.
  • Complies with IEC 61071, UL810, and CSA 22.2 No.190 standards.
  • Compact B2 design with tab terminals.

Specifications

Product ID / Ordering Code E62.G10-202B20
Rated Capacitance (CN) 2 µF
Rated AC Voltage (UN) 2400V AC
RMS Voltage (Urms) 1700V
Surge Voltage (US) 6000V
DC Test Voltage (UTC) 6800V AC
Equivalent Series Resistance (RS) 5.6 mΩ
Thermal Resistance (Rth) 8.5 K/W
Max. Continuous Current (Imax) 16 A
Max. Surge Current (Î) 0.5 kA
Short Circuit Current (IS) 1.5 kA
Equivalent Series Inductance (Le) 120 nH
Dimensions (D1 × L1) 50 × 105 mm
Design / Terminal B2 (6.3 × 0.8 mm single tab)
Weight 0.24 kg
Operating Temperature Range -25 ... +85°C
Hotspot Temperature (ΘHOTSPOT) < 85°C
Capacitance Tolerance ±10% (optional ±5%)
Dissipation Factor (tanδ0) 2 × 10-4
Mounting Position Terminals pointing upwards (vertical)
Standards IEC 61071 (optional IEC 61881)
