ELECTRONICON E50.N15-454nt1 Power Film Capacitor, 450µF 1100VDC, 80A Imax, 85x150mm - Pack of 10

ELECTRONICON E50.N15-454nt1 Power Film Capacitor

The ELECTRONICON E50.N15-454nt1 is a high-performance power film capacitor, meticulously designed for demanding applications within power electronics. This robust component serves critical functions such as DC link filtering, energy storage, and resonant circuit applications in inverters, converters, and various industrial power systems. Its advanced construction and superior electrical characteristics ensure reliable operation, high efficiency, and extended lifespan in harsh electrical environments.

Key Features:

• Capacitance (CN): 450 µF
• Rated DC Voltage (UN): 1100 VDC
• Blocking AC Voltage (UBG): 3840 VAC
• Rated AC Voltage (Ur): 250 V
• Surge Voltage (US): 1650 V
• Blocking DC Voltage (UBB): 1650 VDC
• Maximum Current (Imax): 80 A
• Equivalent Series Inductance (Le): 40 nH
• Energy Storage (EN): 272 Ws
• Thermal Resistance (Rth): 44628 K/W (Note: This value appears unusually high for thermal resistance, suggesting a typo or specific internal metric. Please verify if critical.)
• Diameter (D1): 85 mm
• Length (L1): 150 mm
• Design: NT Series
• Part Quantity: Available as individual units with packing options of 5 pieces per FB8 box.
