Eaton FWC-20A10F 20A 600V Fuses — Current Limiting/Fast Acting Fuse (10 Pcs)

Electrical Characteristics:

• Current Rating: 20 A
• AC Voltage Rating: 600 V AC
• DC Voltage Rating: 700 V DC
• AC Interrupting Rating: 200 kA (RMS Symmetrical)
• DC Interrupting Rating: 50 kA
• Utilization Category: aR (Accompanied semiconductor protection)
• Operating Frequency: 45 Hz to 62 Hz
• Fuse Type: High Speed Fuse, Non-Indicating
• Voltage Type: AC/DC

Performance Data:

• Pre-Arc I²t: 34 A²s
• Clearing I²t: 260 A²s
• Watt Losses: 4.8 W

Physical Specifications:

• Fuse Size: 10 x 38 mm
• Dimensions (Length x Width x Height): 38 mm x 11 mm x 11 mm
• Weight: 8.8 g
• Shape: Cylindrical
• Connection Type: Ferrule End
• Material: Ceramic

Compliance & Certifications:

• Compliances: CE Marked, RoHS Compliant
• Certifications: CSA Certified, UL Recognized

Applications:

• Semiconductor Protection
• DC Common Bus Systems
• DC Drives
• Power Converters/Rectifiers

Compatible Accessories:

• BMM Fuse Block
• CHM Modular Fuse Holder

Manufacturer Information:

• Manufacturer: Eaton Bussmann series
• SKU: FWC-20A10F
• Catalog Number: FWC-20A10F
• UPC: 051712796460
• EAN: 5027590499354
