Eaton Bussmann 10NHG000B NH Fuse, 10A 500VAC, gG/gL Class Size 000 - Pack of 10

The Eaton Bussmann 10NHG000B is a high-precision low-voltage NH fuse-link designed for industrial circuit protection and reliable power distribution. Rated for 10A at 500VAC, this Size 000 fuse belongs to the gG/gL utilization category, providing full-range protection for both electrical cables and downstream equipment. With its square-body design and knife-blade contacts, it offers a robust solution for utility, solar, and wind energy applications.

Key Features

• Versatile Circuit Protection: Classified under gG/gL, this fuse provides efficient protection against both overloads and short circuits in general industrial applications.
• High Rupturing Capacity: Engineered to safely interrupt fault currents up to 120kA at 500V AC, ensuring maximum safety for connected high-value equipment.
• Dual Status Indication: Featuring a combination fuse status indicator (dual indicator), allowing maintenance personnel to easily identify blown fuses from multiple angles.
• Enhanced Connectivity: Equipped with high-conductivity metal-plated copper knife blades for low power loss and secure fitment in blade-end connections.
• Industrial-Grade Durability: Built with a high-strength ceramic body to withstand thermal shocks and environmental stresses common in industrial settings.
• Service Compatibility: Equipped with live metal gripping lugs, making it fully compatible with standard NH fuse extraction tools and various switch-disconnectors (e.g., EBH or EBV series).

Technical Specifications

• Manufacturer: Eaton Bussmann
• Catalog Number: 10NHG000B
• Fuse Size: NH000
• Amperage Rating: 10A
• Voltage Rating: 500V AC
• Breaking Capacity: 120 kA
• Utilization Category: gG/gL
• Frequency Rating: 45Hz to 62Hz
• Body Material: Ceramic
• Contact Type: Knife Blade (Blade End)
• Dimensions: 79 mm (L) x 51 mm (H) x 21 mm (W)
• Certifications: IEC 60269-1, IEC 60269-2, DIN 43620, CE Marked, RoHS Compliant
• Package Quantity: 10 Pieces
