Danfoss MBS5100 060N1036 Pressure transmitter,

Manufacturer: Danfoss Product Type: Pressure Transmitter Series: MBS 5100 Part Number: 060N1261

Specifications:

• Pressure Range (Pe): 0.00 - 10.00 bar (0.00 - 145.00 psi)
• Output Signal: 4 - 20 mA
• Supply Voltage: 10 - 32 V DC
• Accuracy: +/- 0.3 % FS
• Electrical Connection: Plug, acc. to EN 175301-803-A
• Pressure Connection: G 1/4 Male (ISO 228-1)
• Pressure Connection Standard: ISO 228-1
• Pressure Connection Size: 1/4
• Pressure Connection Type: G (Male)
• Proof Pressure: 22 bar (319.0 psi)
• Burst Pressure: > 60 bar (870 psi)
• Compensated Temperature Range: -10 °C to 70 °C (14 °F to 158 °F)
• Ambient Temperature Range: -40 °C to 85 °C (-40 °F to 185 °F)
• Medium Temperature Range: -40 °C to 85 °C (-40 °F to 185 °F)
• Enclosure Rating: IP67
• Shock Resistance: 100 g / 11 ms
• Vibration Resistance: 20 g / 20-2000 Hz
• Response Time: < 4 ms
• Approvals: ABS, BV, CCS, CE, DNV, EAC, GL, KR, LR, NKK, RINA, RMRS, RoHS China, UKCA
