Eaton Bussmann C10G1 Fuse, 1A 500V General Purpose, 120kA, 10x38mm - 10 Pack

Eaton Bussmann Series Low Voltage Cylindrical Fuse

Catalog Number: C10G1

Product Specifications:

• Amperage Rating: 1 A
• Voltage Rating: 500 V AC
• Fuse Size: 10 x 38 mm
• Breaking Capacity: 120 kA
• Frequency Rating: 45 Hz - 62 Hz
• Class: gL/gG (Class C)
• Utilization Category: gG (General purpose, cable and equipment protection)
• Watt Losses: 2.77 W
• Connection: Ferrule end x ferrule end
• Construction Size: 10 mm x 38 mm
• Fuse Shape: Cylindrical
• Material: Ceramic

Physical Dimensions:

• Length/Depth: 38 mm
• Height: 10 mm
• Width: 10 mm
• Weight: 8.2 g

Compliance & Certifications:

• Compliances: CE Marked, GoST-R, RoHS Compliant
• Certifications: IEC 60269
