Eaton Bussmann AMG-175 Fuse, 175A 70VDC, High Current Bolted Blade, 50.8mm Stud Center - Pack of 10

The Eaton Bussmann AMG-175 is a specialized high-ampere bolt-down fuse designed for heavy-duty automotive, marine, and industrial DC power distribution. As part of the AMG (MEGA) series, this fuse provides reliable circuit protection for high-current applications such as battery and alternator connections. Its fast-acting characteristic and robust mechanical design make it the industry standard for protecting high-energy circuits against short circuits and prolonged overcurrent conditions.

Key Features

• High Current Protection: Rated at 175 Amperes, designed to handle primary power feeds and auxiliary high-load circuits.
• Rugged Bolt-Down Design: Features bolted blade terminals that ensure a secure, high-pressure connection, minimizing voltage drop and resisting vibration-induced loosening.
• Enhanced Durability: Constructed with a high-strength thermoplastic housing and high-conductivity copper terminals for long-term reliability in harsh environments.
• Transparent Inspection: Equipped with an element window for easy visual confirmation of the fuse status (blown or intact).
• Industry Compatibility: Standard 2.00-inch (50.8mm) mounting centers allow for easy installation in HMEG fuse holders or dedicated battery distribution blocks.

Technical Specifications

• Manufacturer: Eaton Bussmann
• Catalog Number: AMG-175
• Current Rating: 175A
• Voltage Rating: 70 Vdc
• Fuse Type: High Amp Stud-Mount (Fast Blow)
• Mounting Style: Stud / Bolt-Down (M8 compatible)
• Stud Center Distance: 2.00 in (50.8 mm)
• Dimensions: 68.4 mm (L) x 15.4 mm (W) x 9 mm (H)
• Terminal Material: Copper
• Housing Material: Thermoplastic
• Compliance: RoHS Compliant
• Package Quantity: 10 Pieces
