Eaton Bussmann AMG-150 High Current Fuse, 150A 70VDC, Bolted Blade Stud-Mount - Pack of 10

The Eaton Bussmann AMG-150 is a high-performance, stud-mount electrical fuse engineered for primary circuit protection in high-current automotive and DC power distribution systems. This heavy-duty fuse is designed to provide reliable overcurrent protection for demanding applications such as battery chargers, alternators, and large motor circuits. Featuring a robust bolted blade design, it ensures maximum conductivity and mechanical stability in high-vibration environments.

Key Features

• High Current Protection: Rated at 150 Amperes, specifically calibrated for automotive power feeds and industrial DC circuits.
• Superior Breaking Capacity: Provides an interrupt rating of 2.5 kAIC at 70 Vdc, ensuring safety during high-energy fault conditions.
• Rugged Construction: Built with high-conductivity copper terminals and a heat-resistant thermoplastic housing for long-term durability.
• Secure Installation: Designed for M8 studs with a 2.00-inch (50.8mm) center-to-center mounting distance, facilitating a low-resistance bolted connection.
• Industry Compatibility: Fits standard HMEG fuse holders and is suitable for a wide range of high-ampere power distribution blocks.

Technical Specifications

• Manufacturer: Eaton Bussmann
• Catalogue Number: AMG-150
• Amperage Rating: 150A
• Voltage Rating: 70 Vdc
• Interrupting Rating: 2.5 kA @ 70 Vdc
• Mounting Type: Stud-Mount / Bolted Blade End
• Mounting Centers: 2.00 in (50.8 mm)
• Stud Size: M8
• Terminal Material: Copper
• Housing Material: Thermoplastic
• Indicator: Non-indicating
• Compliances: RoHS Compliant
• Package Quantity: 10 Pieces
