Bently Nevada 330105-02-12-10-02-05 3300 XL 8 mm Reverse Mount Probe (Discontinued), 8 mm Gap, 1.0 m Cable, Miniature ClickLoc Coaxial Connector, PPS Tip, SST Case

Overview: The Bently Nevada part number 330105-02-12-10-02-05 is a 3300 XL-series 8 mm reverse mount proximity probe configured with a 1.0 m cable and miniature ClickLoc coaxial connector. This item is discontinued; replacement part: 330105-02-12-10-02-CN (3300 XL 8 mm Reverse Mount Probe). It was designed for precision shaft displacement and vibration sensing in industrial rotating machinery when a reverse-mount orientation is required.

Key Specifications:

• Manufacturer Part Number: 330105-02-12-10-02-05 (discontinued)
• Product Type: 3300 XL 8 mm Reverse Mount Probe
• Nominal Sensing Gap: 8 mm
• Total Cable Length: 1.0 m (3.3 ft)
• Connector: Miniature ClickLoc coaxial connector
• Agency Approvals: Multiple approvals (factory-configured)
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel (SST)
• Unit Weight: 0.323 kg
• Shipping Weight: 1.5 kg
• Country of Origin: Made in U.S.A
• Certificate of Origin (COO): Available upon request

Features and Benefits:

• Reverse-mount configuration for installations requiring probe insertion from the rear of a housing or pedestal
• 8 mm nominal sensing gap optimized for compatibility with Bently Nevada 3300 XL displacement measurement settings
• Robust materials: PPS probe tip for stable sensing surface and 303/304 SST case for corrosion resistance and mechanical durability
• Miniature ClickLoc coaxial connector ensures secure, repeatable electrical connections and simplifies field installation
• Multiple agency approvals support use in regulated industrial environments

Status and Replacement:

• This specific part number (330105-02-12-10-02-05) is discontinued. Recommended replacement: 330105-02-12-10-02-CN (3300 XL 8 mm Reverse Mount Probe). Verify replacement compatibility (threading, approvals, cable length) before ordering.

Applications:

• Shaft displacement and vibration monitoring on turbines, compressors, pumps, generators, and other rotating equipment
• Retrofit and new installations using Bently Nevada 3300 XL monitoring systems
• Installations requiring reverse-mount probe geometry

Ordering and Notes: Order by the manufacturer part number or request the replacement P/N 330105-02-12-10-02-CN for active production parts. Certificate of Origin available on request. Data presented reflects the manufacturer specifications for the referenced part number.
