AS480 AUTOMATIC VOLTAGE REGULATOR (2 Pieces)

AS480 AUTOMATIC VOLTAGE REGULATOR (2 Pieces)

$100.00 USD
$100.00 USD
Sale Sold out
Shipping calculated at checkout.
Feature Specification
Product Name Automatic Digital Voltage Regulator
Model AVR AS480
Sensing & Power Input 120(95-132)/240(190-264) VAC Single Phase Two Wire
Magnetic Field Output Max 90VDC @ 207VAC Input Voltage
Current Continuous 4A, Non-continuous 10A (within 10s)
Voltage Regulation Accuracy <±1% RMS (Generator Speed Variation within 4%)
Excitation Impedance Min 13Ω, Max 100Ω @ 220V
Response Time <10ms
